Варочный порядок Beraplan 35 hl

brand: Beraplan
Material: stainless steel AISI 304
Inner diameter: 2000 mm
Height conical part: 20 0mm
Volume: maximum 38 Hl
Plate heat exchanger double zone model: RDC 307
Capacity: 30 Hl/h from 85°C to 16°C
cubature_l: 1000
Overview
The micro brewery was manufactured in 1999 by theGerman manufacturer BERAPLAN. All equipment is in good condition. A new wort copper was added in 2018
List of equipment
1. Mash Tun
Made by Beraplan in 1999
Cylindric shape with conical ground
Double sidewall
Insulation
Heated by steam
which can be regulated
Hot and cold water inlet at the bottom
Can be emptied through the bottom
4 CIP balls
PT100
2 agitators
Mach pump with variable speed drive
2. Lauter Tun
Made by Beraplan in 1999
Cylindric shape with flat ground
Material: stainless steel AISI 304
Inner diameter: 2000 mm
Volume: maximum 37 Hl
Filtering ground with trapezoidal perforations
High precision valve to regulate the flow rate
Hot and cold water inlet at the bottom
4 CIP balls
PT100
3. Wort Copper
Made by FRACCHIOLLA in 2018
Heated by steam
Cleanning balls
Temperature sensor
Transfer pump from Alfa Laval Solid C-2 (3 kW)
4. Whirlpool
Made by Beraplan in 1999
Cylindric shape with flat ground
Material: stainless steel AISI 304
Inner diameter: 2000 mm
Volume: maximum 40 Hl
Double sidewall
CIP balls
Transfer pump from Alfa Laval Solid C-2 (2,2 kW)
5. Hot Water Tank
Cylindric shape with flat ground
Material: stainless steel AISI 304
Inner diameter: 2000 mm
Volume: maximum 85 Hl
Double sidewall
CIP balls
Transfer pump from Alfa Laval Solid C-2 (7,5 kW)
Heated by steam with temperature regulation
6. Heat Exchanger
Made by MDC (France)
7. Ice Water Unit
New pump
